Reverse Engineering

We use the very latest metrology grade scanning systems to ensure our reverse engineering process starts with the very best data possible to create CAD models for use in downstream processes.

Reverse Engineering is the process used to obtain 3D digital data of a physical form and create CAD models for use in downstream processes.

This may include:

Benchmarking competitor products
Creating CAD models for use in simulation or Finite Element Analysis (FEA)
Creating models for legacy data of pre-CAD components
Recreation or modification of components
CAD models suitable for machining purposes

Capture Point uses the very latest metrology grade scanning systems to ensure this process starts with the very best data possible.

Backed by years of experience in automotive, industrial & product design and engineering, our engineers begin by listening carefully to your specific requirements for the CAD model. This enables them to tailor the service to provide you the models you require as efficiently and cost effectively as possible.

You may require accurate models for ‘as built’ or may need to correct a part for design intent, create data for missing or damaged geometry, or add symmetry. Whatever your requirement, we have the tools and experience to deliver a tailored service to meet your needs.

If you have a reverse engineering requirement please call us on 07540 257489 to discuss it in more detail.

How Capture Point can help you

REVERSE ENGINEERING

We use the very latest metrology grade scanning systems to ensure our reverse engineering process starts with the very best data possible to create CAD models for use in downstream processes.

3D SCANNING

We produce high resolution 3D scans with industry leading accuracy from 0.03mm. We can 3D scan any object, any size, from just a few mm up to 100m plus and any surface, any colour.

7 AXIS CNC MACHINING

We can quickly create large complex models, mold patterns and sculptures milled in a range of materials from woods, foams, model boards and many more.

3D SCANNER HIRE

Get scanning straight away! Point and shoot 3D scanning with our Peel2 scanner, made by the industry leaders in industrial 3D scanning equipment, Creaform you are guaranteed quality results.

PART INSPECTION / METROLOGY

We scan your parts and align and compare the data to an existing CAD master model, which allows us to quickly see deviations over the object or direct us to inspect specific points.

Case studies

Aston Martin Classic Restoration – Creating the Buck

Very few cars can match the beauty of a classic car like Aston Martin. Capture Point were commissioned to develop a ‘Golden Master’ new buck for the construction of a DB4 GT front end. Read how Capture Point use the very latest in 3D scanning technology and and their automotive engineering knowledge to subtly enhance the original by adding symmetry while keeping all the uniqueness of a hand built vehicle.

Train Carriage Measurement – Damage Assessment

Train Carriage Measurement - Damage Assessment Train Carriage Damage Assessment We were contacted by a large UK based Rail company to conduct measurements of two train carriages, bogies and their large connecting bearings. This was to assess the extent of damage after...

Repairing Art work – Sculpture

Repairing Art Work - Sculpture | Manipulating Scan Data and STL Files Donald Brown, a world renowned sculptor, contacted Capture Point initially to scan a large relief sculpture with the purpose of reducing the size of the work, ready for 3D printing a master suitable...
